The 2026 Harley-Davidson® CVO™ Road Glide® ST is engineered as a performance-oriented touring motorcycle with a strong emphasis on measurable output, structural rigidity, and integrated electronic systems. This model uses a large-displacement V-twin engine, a fully adjustable suspension system, and a chassis configuration designed for stability and controlled handling. The overall length measures 94.9 inches, with a width of 36.4 inches and a height of 50.4 inches. A 64-inch wheelbase, 26-degree rake, and 6.7-inch trail define the motorcycle’s geometry, supporting directional stability at speed while maintaining controlled steering response. The design incorporates a balance between touring dimensions and performance-focused handling characteristics.
High Output Milwaukee-Eight® 121 Engine Configuration
The engine is a Milwaukee-Eight® 121 High Output unit with a displacement of 121 cubic inches or 1,977 cubic centimeters. The bore measures 4.075 inches, and the stroke measures 4.6 inches, creating a long-stroke configuration that supports torque generation. The compression ratio is rated at 11.4 to 1, which contributes to increased combustion efficiency and higher output levels. The valvetrain uses pushrod-operated overhead valves with hydraulic self-adjusting lifters and four valves per cylinder, reducing the need for manual adjustment while maintaining consistent valve operation.
Fuel delivery is handled through Electronic Sequential Port Fuel Injection, which supports controlled fuel metering across varying operating conditions. The lubrication system is pressurized and uses a dry-sump configuration, allowing consistent oil circulation under sustained load. A washable fiberglass air cleaner is included for filtration and serviceability. The exhaust system follows a 2-1-2 layout with tapered mufflers, which supports exhaust flow management while maintaining a structured output profile.
Power Output and Torque Delivery Characteristics
The engine produces 127 horsepower at 4,900 revolutions per minute and 145 foot-pounds of torque at 4,000 revolutions per minute. These figures indicate a strong midrange torque curve, allowing consistent acceleration without requiring high engine speeds. Torque delivery at a relatively low rpm improves throttle response during acceleration and passing maneuvers. The engine torque measurement follows the J1349 standard, ensuring consistency in reported performance values.
The drivetrain includes a six-speed Cruise Drive® transmission. Gear ratios range from 10.233 in first gear to 3.067 in sixth gear, providing a broad spread between low-speed control and highway cruising efficiency. The clutch is a mechanically actuated 10-plate wet design with Assist and Slip functionality, which reduces lever effort and manages rear wheel behavior during downshifts. The primary drive uses a chain with a 34 to 46 ratio, while the final drive uses a belt with a 30 to 68 ratio. This combination supports durability and smooth power transfer.
Structural Frame and Chassis Composition
The frame is constructed from mild steel using a tubular structure with a two-piece stamped and welded backbone. Cast and forged junctions are integrated into the frame to improve strength at critical connection points. The chassis includes twin down tubes and a bolt-on rear frame section with forged fender supports. The swingarm is also constructed from mild steel with a two-piece drawn and welded design and forged junctions. These construction methods support rigidity and load distribution during operation.
The 2026 Harley-Davidson® CVO™ Road Glide® ST has a running order weight of 838 pounds and a gross vehicle weight rating of 1,360 pounds. Front axle weight rating is 500 pounds, while the rear axle rating is 927 pounds. These figures define load capacity and distribution limits. Ground clearance is measured at 5.1 inches, which supports lean angle capability while maintaining underbody clearance.
Suspension System with Multi-Axis Adjustability
The front suspension consists of 47 mm inverted 1x1 forks with adjustable preload, compression damping, and rebound damping. This configuration allows riders to adjust the suspension based on load conditions and road surface variations. Rear suspension uses an emulsion shock system with adjustable preload, compression damping, and rebound damping. This provides a consistent damping response and allows for tuning across different riding scenarios.
Front suspension travel is 4.6 inches, and rear suspension travel is 3 inches. These values support a balance between ride compliance and chassis control. The suspension system is designed to maintain tire contact and stability during braking, acceleration, and cornering inputs. The adjustability enables fine-tuning without requiring component replacement.
Wheel and Tire Configuration for Stability
The 2026 Harley-Davidson® CVO™ Road Glide® ST is equipped with black 7-spoke cast aluminum wheels. The front wheel measures 19 inches in diameter and 3.5 inches in width, while the rear wheel measures 18 inches in diameter and 5 inches in width. Tire specifications include a 130/60B19 front tire and a 180/55B18 rear tire, both from the Dunlop® Harley-Davidson® Series.
This tire configuration supports traction, load handling, and directional stability. The wider rear tire contributes to grip during acceleration, while the front tire supports steering precision. The combination is selected to match the motorcycle’s weight and performance characteristics.
Brake System Design and Control Integration
The braking system uses dual 12.6-inch wave-style floating rotors at the front with 4-piston fixed radial-mounted calipers. The rear brake uses an 11.8-inch fixed rotor with a single axial-mounted caliper. This configuration provides consistent braking force distribution and heat management during repeated braking cycles.
Anti-lock Braking System is standard, allowing controlled braking under varying traction conditions. The braking system is integrated with electronic control features that support stability and rider input modulation. Rotor thickness measures 0.18 inches at the front and 0.28 inches at the rear, contributing to structural integrity and heat dissipation.
Rider Safety Systems and Electronic Control Features
The 2026 Harley-Davidson® CVO™ Road Glide® ST includes a comprehensive set of rider safety systems. Standard features include Anti-lock Braking System, Electronic Linked Braking, Traction Control System, Drag-torque Slip Control System, Vehicle Hold Control, and Tire Pressure Monitoring System. These systems operate together to regulate braking force, maintain traction, and provide stability during various riding conditions.
Cornering-enhanced systems are also included. These consist of a Cornering Enhanced Anti-lock Braking System, Cornering Enhanced Electronic Linked Braking, Cornering Enhanced Traction Control System, and Cornering Drag-torque Slip Control System. These systems adjust performance based on lean angle input, improving control during cornering.
Lean angle capability is rated at 31 degrees on both the left and right sides. This specification indicates the motorcycle’s capacity to maintain traction and stability during angled riding positions.
Electrical System and Integrated Lighting
The electrical system includes a sealed, maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold cranking amps. Charging is handled by a three-phase 58-amp system with a maximum output of 754 watts at 13 volts. The starting system uses a 1.6 kilowatt electric starter with solenoid engagement.
Lighting is fully LED-based, including the headlamp, tail and stop lamp, and turn signals. LED components provide consistent illumination and energy efficiency. The motorcycle also includes digital gauges integrated into the display, allowing consolidated monitoring of vehicle data.
A USB-C power outlet rated at 15 watts is located in the media storage compartment. This allows device charging during operation and supports connectivity functions.
Infotainment System and Connectivity Functions
The infotainment system operates on Skyline™ OS and is displayed on a 12.3-inch full-color TFT screen. The display integrates vehicle data, navigation, and media functions into a single interface. Audio output is rated at 125 watts per channel, with two 6.5-inch speakers mounted in the fairing.
The system includes AM and FM radio functionality. Bluetooth® connectivity supports hands-free phone use and media playback. Apple CarPlay® compatibility is available in both wired and wireless formats. USB-C and MTP connections allow integration with external devices, including smartphones and storage media.
Navigation is embedded and includes traffic and weather information through a Wi-Fi hotspot connection. The system also supports text-to-speech functionality and displays vehicle information such as air temperature and oil pressure.
Dimensions, Capacity, and Operational Range
Fuel capacity is 6 gallons, with a reserve indicator at 1 gallon. Fuel economy is estimated at 44 miles per gallon based on combined city and highway operation. Oil capacity is 5 quarts with a filter, while transmission capacity is 1 quart. The primary chain case holds 1.1 quarts, and coolant capacity is 0.82 quarts.
Seat height measures 27.5 inches when laden and 28.3 inches when unladen. These measurements are based on a standard operator weight. The configuration supports rider accessibility while maintaining ground clearance. Luggage capacity is rated at 2.42 cubic feet, providing storage for touring use without altering structural balance.
