The 2026 Harley-Davidson® CVO™ Street Glide® 3 Limited is engineered as a full-scale touring motorcycle with a focus on mechanical efficiency, system integration, and long-distance capability. Its design incorporates a large-displacement engine, a reinforced chassis structure, and a complete suite of electronic control systems.
The model measures 105.7 inches in length, 57.3 inches in width, and 56.5 inches in height. The wheelbase extends to 67.7 inches, supporting balanced weight distribution. Seat height is 27.3 inches when laden and 28.9 inches when unladen. Ground clearance measures 5.1 inches. These dimensions position the motorcycle for controlled handling and rider accessibility during both stationary and dynamic conditions.
Engine Architecture and Output Characteristics
The motorcycle uses the Milwaukee-Eight® VVT 121 engine. This engine displaces 121 cubic inches, equivalent to 1,977 cubic centimeters. The bore measures 4.075 inches, and the stroke measures 4.625 inches. Compression is set at 11.4 to 1, allowing for efficient combustion and consistent output.
The valve system uses pushrod-operated overhead valves with four valves per cylinder. Hydraulic, self-adjusting lifters maintain valve clearance without manual adjustment. Variable Valve Timing adjusts valve operation based on engine speed and load, improving efficiency across different operating ranges.
Fuel delivery is managed by Electronic Sequential Port Fuel Injection. The system meters fuel precisely to each cylinder, supporting consistent throttle response. The engine uses a 2-1-2 dual exhaust configuration, which supports exhaust flow and contributes to torque delivery.
Output figures include 138 foot-pounds of torque at 3,750 rpm and 114 horsepower at 4,500 rpm. These values indicate strong low- to mid-range performance, which is critical for touring applications. The lubrication system uses a pressurized dry-sump design to maintain oil circulation during prolonged operation.
Transmission and Drivetrain Configuration
The drivetrain system uses a chain primary drive with a 34 to 46 ratio and a belt final drive with a 30 to 70 ratio. This combination reduces maintenance while maintaining efficient power transfer.
The transmission is a 6-speed Cruise Drive® unit equipped with reverse. Gear ratios are configured as follows: first gear at 10.534, second gear at 7.302, third gear at 5.423, fourth gear at 4.392, fifth gear at 3.742, and sixth gear at 3. These ratios allow progressive acceleration and reduced engine speed at highway cruising speeds.
The clutch is a mechanically actuated 10-plate wet system with assist and slip functionality. This design reduces lever effort and helps prevent rear-wheel instability during aggressive downshifts. The electric reverse system is controlled from the handlebar and assists in maneuvering at low speeds.
Frame Design and Suspension Components
The frame uses a mild steel, square-section backbone with twin downtubes. This configuration provides structural rigidity while supporting the motorcycle’s weight. The swingarm is constructed from permanent mold cast aluminum, reducing unsprung weight and improving durability.
The front suspension uses a 49 millimeter dual-bending valve fork. This system improves damping control and reduces front-end dive during braking. Rear suspension consists of hand-adjustable emulsion shocks, allowing riders to modify preload based on load conditions.
Suspension travel measures 4.6 inches at the front and 3.46 inches at the rear. Steering geometry includes a rake angle of 26 degrees and a trail measurement of 3.8 inches. These values contribute to directional stability and predictable steering response.
Wheels, Tires, and Ground Contact Systems
The motorcycle is equipped with dual grain chrome 14-spoke wheels. The front wheel measures 19 inches in diameter and 3.5 inches in width. The rear wheel measures 18 inches in diameter and 7 inches in width.
The front tire is specified as 130 over 60B19. The rear tire is specified as P215/45R18. The front tire uses a bias construction, while the rear uses a radial design. This combination supports both load capacity and traction under touring conditions.
Braking System and Control Integration
The braking system uses dual front rotors with a diameter of 11.8 inches and a thickness of 0.197 inches. The front calipers are fixed 32-millimeter 4-piston units. The rear brake uses a single rotor with the same diameter and a thickness of 0.276 inches, paired with a floating 36-millimeter piston caliper that includes an integrated parking brake.
Anti-lock Braking System functionality is standard. Electronic Linked Braking distributes braking force between the front and rear wheels. These systems work together to maintain stability during braking.
Additional control systems include the Traction Control System and Drag-Torque Slip Control System. Vehicle Hold Control assists when stopped on inclines. A tire pressure monitoring system provides continuous pressure readings.
Cornering enhancements include a cornering Anti-lock Braking System, cornering Electronic Linked Braking, and a cornering Traction Control System. These systems adjust braking and torque output based on lean angle, improving stability during turns.
Electrical System and Lighting Configuration
The electrical system uses a sealed, maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold cranking amps. Charging is handled by a three-phase 48-amp system capable of producing up to 625 watts.
The starting system uses a 1.6 kilowatt electric starter motor with solenoid engagement. Lighting is fully LED-based, including headlamp, tail and stop lights, and turn signals. LED fog lamps are integrated into the lower fairings to improve visibility.
A 15-watt USB-C power outlet is located in the media storage compartment. This allows for device charging during operation. Digital gauges are integrated into the main display, providing system data and vehicle information.
Infotainment System and Connectivity Features
The infotainment system uses Skyline™ OS and is displayed on a 12.3-inch full-color TFT screen. This system integrates navigation, communication, and audio controls into a single interface.
The audio system includes six speakers. Output is rated at 125 watts across four channels and 150 watts across two channels. Speaker placement includes fairing-mounted units, lower fairing speakers, and Tour-Pak® speakers.
Connectivity includes Bluetooth® for phone and media functions. Apple CarPlay® is supported through both wired and wireless connections. USB-C connectivity allows media playback and device integration.
The system supports rider and passenger intercom functionality. A wireless Bluetooth® headset option is available for communication. Navigation is embedded within the system and includes traffic and weather data through a Wi-Fi connection.
Vehicle information such as air temperature and oil pressure is displayed through the interface. Text-to-speech functionality supports navigation prompts.
Fuel Capacity and Efficiency Metrics
The fuel tank holds 6 gallons. A reserve capacity of 1 gallon is indicated by a warning light. Estimated fuel economy is 39 miles per gallon under combined city and highway conditions.
The oil capacity with the filter is 5 quarts. The transmission holds 1.22 quarts, and the primary chain case holds 1.1 quarts. Coolant capacity is 0.82 quarts. These values support sustained operation during long-distance travel.
Weight Distribution and Load Capacity
The motorcycle has a weight of 1,243 pounds as shipped and 1,283 pounds in running order. The Gross Vehicle Weight Rating is 1,700 pounds. The front axle rating is 511 pounds, and the rear axle rating is 1,189 pounds.
Luggage capacity measures 7.1 cubic feet. This volume supports extended touring requirements and passenger accommodations. The weight distribution and load ratings ensure structural integrity under maximum capacity.
Functional Integration and Touring Capability
The combination of engine output, drivetrain configuration, and chassis design supports long-distance travel with consistent performance. Suspension and braking systems maintain stability under varying loads. Electronic systems provide continuous adjustments to traction and braking, improving control during changing conditions.
The integration of infotainment and navigation systems allows centralized access to ride data and communication functions. Electrical capacity supports both vehicle systems and external device charging.
