The 2026 Harley-Davidson® CVO™ Street Glide® is engineered as a premium touring motorcycle focused on high-displacement performance, integrated rider technology, and balanced chassis design. This model combines a large-capacity V-twin engine, advanced electronic rider aids, and a refined suspension system intended for long-distance riding stability. The specifications emphasize measurable performance values, dimensional precision, and consistent mechanical operation. Its design follows a factory-custom approach that prioritizes integration between powertrain, frame, infotainment, and braking systems.
The motorcycle measures 94.9 inches in overall length with a wheelbase of 64 inches, creating a stable platform suitable for highway travel. Overall width is listed at 38.4 inches and overall height at 53.1 inches, resulting in a touring-focused riding posture and aerodynamic profile. Seat height is specified at 26.7 inches laden and 28.2 inches unladen, supporting controlled rider access while maintaining long-distance comfort. Ground clearance is rated at 5.5 inches, allowing adequate lean capability with touring practicality. These dimensions work together to establish predictable handling characteristics and consistent rider ergonomics during extended operation.
Engine Output and Mechanical Engineering
The 2026 Harley-Davidson® CVO™ Street Glide® uses the Milwaukee-Eight® VVT 121 engine, a displacement configuration measuring 121 cubic inches or 1,977 cc. This engine uses pushrod-operated overhead valves with hydraulic self-adjusting lifters and four valves per cylinder. Bore is measured at 4.075 inches, while the stroke measures 4.625 inches, supporting strong low-end torque and steady power delivery across the operating range. The compression ratio is specified at 11.4:1, contributing to combustion efficiency and responsiveness.
Power output is rated at 115 horsepower at 4,500 rpm. Engine torque is listed at 139 ft-lb at 3,000 rpm, reflecting the engine’s emphasis on sustained pulling power rather than peak rpm performance. The torque testing method follows J1349 standards, ensuring consistency in measurement. Fuel delivery is managed by Electronic Sequential Port Fuel Injection, which controls fuel flow accurately for throttle response and efficiency.
The intake system uses a synthetic felt washable air cleaner. Exhaust routing follows a 2-1-2 dual exhaust configuration, supporting balanced flow while maintaining touring acoustics. Lubrication relies on a pressurized dry-sump system, which improves oil circulation stability during prolonged riding and varying engine loads. This mechanical setup supports durability while maintaining consistent performance during extended operation.
Drivetrain Configuration and Gear Management
Power from the engine transfers through a chain-driven primary drive using a 34/46 ratio, followed by a belt final drive with a 32/68 ratio. This combination balances durability with smooth operation for touring applications. The clutch system is mechanically actuated and uses a 10-plate wet design incorporating Assist and Slip technology, which reduces lever effort and helps manage rear wheel stability during downshifts.
Transmission duties are handled by a 6-Speed Cruise Drive® gearbox. Gear ratios are spaced to support controlled acceleration and relaxed highway cruising. First gear carries an overall ratio of 9.593, providing strong low-speed drive. Second through sixth gears progressively reduce ratios down to 2.875 in top gear, allowing reduced engine speed at higher travel speeds. This layout supports fuel efficiency and reduced vibration during long rides while maintaining sufficient torque availability for passing or loaded touring conditions.
Frame Design and Structural Geometry
The chassis uses a mild steel tubular frame incorporating a two-piece stamped and welded backbone with cast and forged junctions. Twin down tubes increase rigidity and maintain structural alignment under load. The bolt-on rear frame section with forged fender supports contributes to serviceability while supporting luggage and passenger weight. All major welded areas use MIG welding for consistent manufacturing quality.
The swingarm is constructed from mild steel using a two-piece drawn and welded design with forged junctions. This structure contributes to rear-end stability and predictable suspension movement under acceleration and braking loads. Steering geometry includes a rake angle of 26 degrees with a fork angle of 30 degrees and a trail measurement of 6.7 inches. These figures are tuned for a balance between steering precision and long-distance directional stability.
Running weight is specified at 838 pounds, with a shipping weight of 800 pounds. Gross vehicle weight rating is listed at 1,360 pounds, supporting passenger use and luggage capacity without compromising structural integrity.
Suspension Systems and Road Control
Front suspension consists of 47 mm inverted 1x1 forks designed to increase rigidity and improve steering response. This fork design supports stable braking performance while maintaining consistent damping characteristics through varying road surfaces. Rear suspension uses dual adjustable emulsion shocks. The left shock includes remote preload adjustment, while the right shock uses threaded preload adjustment, allowing riders to configure suspension performance based on load and riding conditions.
Front suspension travel is specified at 4.6 inches, while rear travel measures 3 inches. This combination supports touring comfort while retaining adequate feedback for controlled handling. Lean angles are rated at 32 degrees on both the left and right sides, indicating a balance between touring clearance and cornering ability.
Wheels are gloss black, nine-spoke cast aluminum units sized at 19 inches in the front and 18 inches in the rear. Front wheel width is 3.5 inches, and rear width measures 5 inches. Tires are specified as Dunlop® Harley-Davidson® Series bias blackwall models, with a 130/60B19 front and 180/55B18 rear configuration. These specifications contribute to stability at higher speeds and predictable corner entry behavior.
Braking Systems and Rider Safety Enhancements
Braking components are designed to provide consistent stopping performance across touring conditions. The front uses dual 32 mm 4-piston fixed radially mounted calipers paired with dual floating rotors measuring 12.6 inches in diameter and 0.18 inches in thickness. Rear braking uses a single axially mounted caliper with an 11.8-inch rotor measuring 0.28 inches thick.
Anti-lock Braking System is standard equipment, supporting braking stability under reduced traction. Electronic Linked Braking coordinates front and rear brake application for balanced deceleration. The Traction Control System monitors rear wheel slip and adjusts output when required. Drag-torque Slip Control System limits rear wheel instability during aggressive downshifting. Vehicle Hold Control assists during stops on inclines by maintaining brake pressure temporarily. The Tire Pressure Monitoring System continuously monitors tire pressures to support safety and handling consistency.
Cornering rider safety enhancements include cornering-enhanced ABS, cornering electronic linked braking, cornering traction control, and cornering drag-torque slip control. These systems adjust responses according to lean angle data to maintain predictable operation during cornering maneuvers.
Electrical Architecture and Lighting Systems
The electrical system uses a sealed, maintenance-free 12-volt battery rated at 28 amp-hours with 405 cold cranking amps. Charging is managed by a three-phase 58-amp system capable of producing up to 754 watts at 13 volts. This output supports infotainment, lighting, and accessory power demands without compromising charging stability.
Starting is handled by a 1.6 kW electric system using a solenoid shift starter motor. Lighting across the motorcycle uses LED technology, including headlamp, tail and stop lights, front signals, and rear turn signals. LED components improve longevity and reduce electrical load while maintaining visibility standards. Digital gauges are integrated within the display system, consolidating essential information into a centralized visual interface.
An integrated USB-C electric power accessory port rated at 15 watts is positioned inside the media storage compartment, allowing continuous device power while riding.
Infotainment and Connectivity Systems
The infotainment platform uses Skyline™ OS displayed on a 12.3-inch full-color TFT screen. The display provides access to vehicle information, media, navigation, and connectivity features. Audio output is rated at 125 watts per channel through four speakers. Two 6.5-inch speakers are mounted in the fairing, and two 5x7-inch speakers are positioned in the saddlebags to distribute sound evenly.
Connectivity includes wireless and wired Apple CarPlay® compatibility, Bluetooth® integration for phone and media playback, and support for headset pairing. Hands-free mobile phone functionality is included. Rider and passenger intercom capability is supported when compatible headsets are used. Navigation functionality is embedded within the system and supported through a Wi-Fi hotspot connection.
Vehicle information screens provide operational data, including air temperature, oil pressure, and engine management information. USB-C and MTP connectivity allow smartphone or media connection through the inner fairing storage compartment.
Fuel Capacity, Range Efficiency, and Operational Data
Fuel capacity is listed at 6 gallons, with a reserve capacity warning at 1 gallon. Estimated fuel economy is rated at 45 mpg, providing a balance between performance output and touring range. Oil capacity with filter is 5 quarts, while transmission capacity is 1 quart and primary chain case capacity is 1.1 quarts. Coolant capacity is listed at 0.82 quarts. These specifications support consistent thermal management and maintenance planning during long-distance use.
Luggage volume totals approximately 2.2 cubic feet, supporting storage needs for extended riding. Weight distribution and chassis geometry are calibrated to maintain stability with added cargo load.
