The 2026 Harley-Davidson® Road Glide® is designed for long-distance touring with a focus on engine performance, chassis stability, integrated technology, and rider assistance systems. The motorcycle uses the Milwaukee-Eight® 117 powertrain, a six-speed transmission, a frame-mounted fairing configuration, and a full-color TFT infotainment display. Its specifications include 105 horsepower, 130 ft-lb of torque, electronic rider safety systems, and integrated navigation capability. The platform combines touring dimensions, advanced braking technology, and digital connectivity in a motorcycle configured for extended highway operation and consistent handling performance.
Milwaukee-Eight® 117 Engine Configuration
The 2026 Harley-Davidson® Road Glide® uses the Milwaukee-Eight® 117 engine. This V-Twin engine features a displacement of 117 cubic inches, or 1,923 cc. The engine uses a bore measuring 4.075 inches and a stroke measuring 4.5 inches. Compression ratio is rated at 10.3:1. The valve train uses pushrod-operated overhead valves with hydraulic self-adjusting lifters and four valves per cylinder.
Fuel delivery is handled through Electronic Sequential Port Fuel Injection. This system supports consistent throttle response and stable fuel metering during acceleration and highway operation. Harley-Davidson® equips the engine with a washable fiberglass air cleaner and a pressurized dry-sump lubrication system. The exhaust configuration uses a 2-1-2 dual exhaust system with tapered mufflers.
The engine produces 130 ft-lb of torque at 3,250 rpm. Maximum output is rated at 105 horsepower at 4,600 rpm. These performance figures support strong low-rpm pulling capability and steady highway cruising performance. The engine torque testing method follows the J1349 standard.
Fuel economy is rated at an estimated 44 mpg. The motorcycle uses a 6-gallon fuel tank with a 1-gallon reserve fuel warning capacity. Oil capacity with filter is listed at 5 quarts. Transmission capacity measures 1 quart, while the primary chain case capacity is 1.1 quarts. Coolant capacity is listed at 0.82 quarts.
Six-Speed Drivetrain and Power Transfer
The 2026 Harley-Davidson® Road Glide® uses a 6-Speed Cruise Drive® transmission. This transmission is paired with a chain primary drive using a 34/46 ratio and a belt final drive using a 32/68 ratio. Harley-Davidson® also equips the motorcycle with a mechanically actuated 10-plate wet Assist and Slip clutch.
The gear ratios provide a broad operating range for city riding and highway travel. First gear uses an overall ratio of 9.593. Second gear is rated at 6.65, while third gear is listed at 4.938. Fourth gear uses a ratio of 4.0. Fifth gear is rated at 3.407, and sixth gear uses a ratio of 2.875. These ratios support reduced engine speed during extended highway riding while maintaining strong acceleration characteristics in lower gears.
The Assist and Slip clutch system contributes to smoother downshifts and more controlled deceleration during aggressive throttle reduction. Combined with the six-speed transmission, the drivetrain is configured for touring stability and predictable power delivery.
Touring Chassis and Structural Design
The frame of the 2026 Harley-Davidson® Road Glide® uses a mild-steel tubular structure with a two-piece stamped and welded backbone. The frame incorporates cast and forged junctions, twin down-tubes, and a bolt-on rear frame section with forged fender supports. Harley-Davidson® uses MIG welding throughout the frame structure.
The swingarm uses a mild-steel two-piece drawn and welded section with forged junctions and MIG-welded construction. The overall chassis design is intended to support touring stability, luggage capacity, and highway handling consistency.
The motorcycle has a wheelbase measuring 64 inches. Steering geometry includes a 26-degree rake and a 29.25-degree fork angle. Trail is listed at 6.8 inches. The 2026 Harley-Davidson® Road Glide® measures 94.9 inches in total length, 37.2 inches in width, and 51.8 inches in height.
Laden seat height measures 26.6 inches. Unladen seat height is listed at 28.3 inches. Static ground clearance measures 5.7 inches. The motorcycle has an as-shipped weight of 802 pounds and a running order weight of 838 pounds. Gross vehicle weight rating is listed at 1,360 pounds.
The luggage compartment provides 2.42 cubic feet of storage capacity. This touring-oriented storage configuration supports extended travel requirements while maintaining integrated bodywork dimensions.
Suspension and Wheel Specifications
The front suspension system uses a 49 mm Dual Bending Valve fork. Front suspension travel measures 4.6 inches. Rear suspension uses dual outboard emulsion shocks with preload adjustability and 3 inches of rear suspension travel.
The suspension configuration supports highway stability, rider control, and load adjustment capability. Preload adjustability allows riders to compensate for passenger weight and luggage requirements during touring operation.
The 2026 Harley-Davidson® Road Glide® rides on cast aluminum wheels. The front wheel measures 19 inches in diameter and 3.5 inches in width. The rear wheel measures 18 inches in diameter and 5 inches in width.
Harley-Davidson® equips the 2026 Harley-Davidson® Road Glide® with Dunlop® Harley-Davidson® Series bias blackwall tires. The front tire uses a D408F specification in size 130/60B19 M/C 61H. The rear tire uses a D407T specification in size 180/55B18 M/C 80H.
Lean angle capability is rated at 32 degrees on both the left and right sides. Lean angle testing follows SAE J1168 standards.
Integrated Braking and Rider Assistance Systems
The braking system of the 2026 Harley-Davidson® Road Glide® uses dual floating front rotors and a fixed rear rotor. Front brake diameter measures 12.6 inches with a thickness of 0.18 inch. The rear brake diameter measures 11.8 inches with a thickness of 0.28 inch.
The front brake system uses dual 32 mm four-piston fixed axially mounted calipers. The rear brake uses a single axially mounted caliper. Dual front braking configuration contributes to controlled stopping performance during highway operation and loaded touring conditions.
Anti-lock Braking System is included as standard equipment. The motorcycle also includes Electronic Linked Braking, which distributes braking force between front and rear systems during braking input.
Additional rider assistance systems include the Traction Control System, Drag-torque Slip Control System, Vehicle Hold Control, and Tire Pressure Monitoring System. These systems assist with traction management, hill-start control, deceleration stability, and tire pressure awareness.
The 2026 Harley-Davidson® Road Glide® also includes cornering-enhanced rider safety technologies. These systems include the Cornering Enhanced Anti-lock Brake System, Cornering Enhanced Electronic Linked Braking, Cornering Enhanced Traction Control System, and Cornering Drag-Torque Slip Control System. These systems use motorcycle lean-angle data to adjust braking and traction intervention during cornering conditions.
Electrical Equipment and Lighting Systems
The electrical system uses a sealed maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold-cranking amps. Charging capability is handled through a three-phase 58-amp charging system with a maximum output of 754 watts at 13 volts.
Starting operation uses a 1.6 kW electric starter with solenoid shift starter motor engagement. This configuration supports consistent engine starting performance under varying operating conditions.
Lighting equipment is fully LED-based. The headlamp, tail and stop lamp, front signal lamps, and rear turn signals all use LED technology. LED lighting contributes to reduced electrical load and increased visibility.
Digital gauges are integrated directly within the infotainment display system. The motorcycle also includes a 15-watt USB-C electric power accessory port located inside the media storage compartment.
Skyline™ OS Infotainment and Connectivity Features
The 2026 Harley-Davidson® Road Glide® uses the Skyline™ OS infotainment platform. The system operates through a 12.3-inch full-color TFT display integrated into the fairing layout. The display combines navigation, audio controls, vehicle information, and communication functions within a centralized interface.
Audio output is rated at 50 watts per channel. The system uses two 5.25-inch fairing-mounted speakers. AM and FM radio capabilities are included as standard equipment.
USB connectivity supports SD card, flash drive, and MP3 media playback through USB connection compatibility. Bluetooth® functionality supports mobile phone connection, media player integration, and headset communication capability.
Apple CarPlay® compatibility is included through wired or wireless connection. Rider and passenger intercom support is available when compatible Harley-Davidson® headsets are installed. VOX functionality is available with H-D headset systems.
The integrated vehicle information screen displays operational data including air temperature, oil pressure, and EITMS information. The motorcycle also includes an embedded GPS navigation system with traffic and weather capability through Wi-Fi hotspot functionality in supported markets.
Touring Dimensions and Operational Specifications
The 2026 Harley-Davidson® Road Glide® combines touring-oriented dimensions with integrated rider accommodations and operational efficiency. Tire and wheel specifications are configured to support highway tracking stability and predictable steering response. Suspension travel and chassis geometry contribute to controlled cornering characteristics during long-distance travel.
The motorcycle uses a laden seat height intended to support rider accessibility during stop-and-go riding conditions. Ground clearance measurements and lean-angle capability are balanced to maintain touring functionality while preserving cornering capability.
Fluid capacities and maintenance access points are configured for touring operation and scheduled servicing intervals. The combination of fuel capacity, engine output, and transmission gearing supports extended riding range and sustained highway operation.
