The 2026 Harley-Davidson® Street Glide® Limited is a fully equipped touring motorcycle designed to combine long-distance capability with advanced rider technology, integrated storage, and a large-displacement V-twin powertrain. Built around the Milwaukee-Eight® VVT 117 engine, the model incorporates a broad range of mechanical, electronic, and comfort-oriented systems intended to support extended travel. Its specification package includes advanced rider safety technologies, a full-color infotainment system, integrated navigation, adjustable suspension components, and substantial luggage capacity. The motorcycle also features a robust chassis structure, modern lighting systems, and connectivity features that support communication and navigation functions.
Engine Design and Performance
The 2026 Harley-Davidson® Street Glide® Limited is powered by the Milwaukee-Eight® VVT 117 engine, a 117 cubic-inch powerplant that displaces 1,923 cc. The engine utilizes a pushrod-operated overhead valve configuration with hydraulic self-adjusting lifters and four valves per cylinder. A bore of 4.075 inches and a stroke of 4.5 inches contribute to the engine’s displacement and operating characteristics, while a 10.3:1 compression ratio supports its performance profile. Fuel delivery is managed through Electronic Sequential Port Fuel Injection, providing precise fuel metering across a range of operating conditions. The engine also incorporates a fiberglass washable air cleaner and a 2-1-2 dual exhaust system fitted with tapered mufflers.
Power Output and Torque Characteristics
Performance figures highlight the capabilities of the Milwaukee-Eight® VVT 117 engine. The powerplant produces 131 ft-lb of torque at 3,250 rpm using the J1349 testing method and generates 106 horsepower, or 79 kW, at 4,600 rpm. These specifications indicate strong low- and mid-range output characteristics that align with the motorcycle’s touring-focused design. The engine operates with a pressurized dry-sump lubrication system that helps manage lubrication demands during extended operation. Together, the displacement, torque output, fuel injection system, and lubrication design create a comprehensive powertrain package engineered for sustained touring performance.
Fuel and Fluid Capacities
The 2026 Harley-Davidson® Street Glide® Limited carries 6 gallons, or 22.7 liters, of fuel, providing substantial onboard fuel capacity for longer riding distances. A fuel injection warning light is supported by a 1-gallon reserve capacity. Engine oil capacity with filter is rated at 5 quarts, while transmission capacity measures 1 quart. The primary chain case holds 1.1 quarts of fluid, and coolant capacity is listed at 0.82 quarts. These capacities support the motorcycle’s touring mission by accommodating the operational requirements of its engine, drivetrain, and cooling systems.
Drivetrain and Transmission Systems
The drivetrain of the 2026 Harley-Davidson® Street Glide® Limited is engineered to transfer power efficiently from the Milwaukee-Eight® VVT 117 engine to the rear wheel. The primary drive utilizes a chain system with a 34/46 ratio, while the final drive uses a belt configuration with a 32/68 ratio. This arrangement integrates with a mechanically actuated 10-plate wet Assist and Slip clutch that manages power engagement and driveline control. The combination of a chain primary drive, a belt final drive, and an Assist and Slip clutch creates a complete drivetrain package tailored to the motorcycle’s performance and touring objectives.
Six-Speed Cruise Drive® Transmission
A 6-Speed Cruise Drive® transmission manages gear selection and power delivery. The transmission features six distinct overall gear ratios, beginning with a 9.593 ratio in first gear and progressing through ratios of 6.65, 4.938, 4.0, and 3.407 before reaching a 2.875 ratio in sixth gear. This progression provides a structured range of gearing across varying riding conditions and speeds. The six-speed configuration complements the engine’s torque characteristics and supports highway-oriented operation. Together, the transmission and drivetrain components form a cohesive mechanical system designed for touring-focused performance.
Chassis Architecture and Dimensions
The 2026 Harley-Davidson® Street Glide® Limited is built around a mild-steel tubular frame that incorporates a two-piece stamped and welded backbone. The structure utilizes cast and forged junctions, twin down-tubes, and a bolt-on rear frame with forged fender supports. MIG welding is employed throughout the frame construction process. The swingarm is also constructed from mild steel and features a two-piece drawn and welded design with forged junctions. These structural components establish the motorcycle’s foundational architecture and support its overall size, weight, and load-carrying capabilities.
Physical Dimensions and Geometry
The motorcycle measures 103.3 inches in overall length, 40.7 inches in overall width, and 56.7 inches in overall height. A wheelbase of 64 inches contributes to the model’s overall proportions, while steering geometry consists of a 26-degree rake, a 29.25-degree fork angle, and 6.7 inches of trail. Seat height is listed at 27.5 inches when laden and 29.1 inches when unladen. Static ground clearance measures 5.9 inches. These dimensions establish the motorcycle’s physical footprint and provide important context regarding rider positioning, chassis geometry, and overall design.
Weight Ratings and Load Capacity
The 2026 Harley-Davidson® Street Glide® Limited has an as-shipped weight of 855 pounds and a running-order weight of 893 pounds. The Gross Vehicle Weight Rating is specified at 1,360 pounds. The front Gross Axle Weight Rating is 500 pounds, while the rear Gross Axle Weight Rating is 927 pounds. These ratings define the motorcycle’s designed operating limits and load-handling parameters. The combination of structural construction and weight specifications supports the motorcycle’s intended touring role.
Suspension, Wheels, and Tires
The suspension system of the 2026 Harley-Davidson® Street Glide® Limited combines front and rear components designed to support rider comfort and chassis control. At the front, the motorcycle utilizes a 49 mm Dual Bending Valve fork. This front suspension works in conjunction with a rear suspension system that features dual adjustable emulsion shocks. The left rear shock includes remote preload adjustment, while the right rear shock incorporates threaded preload adjustment. These components provide tunable suspension characteristics within the motorcycle’s specified configuration.
Suspension Travel and Ride Control
Front suspension travel measures 4.6 inches, while rear suspension travel is rated at 3 inches. These travel figures define the operational movement available within the suspension system and contribute to ride quality and chassis behavior. The adjustable rear suspension configuration allows preload changes through dedicated adjustment mechanisms. Combined with the front fork design, the suspension system forms an integrated chassis-control package. The result is a suspension arrangement designed to support the motorcycle’s touring-focused architecture.
Wheel and Tire Specifications
The 2026 Harley-Davidson® Street Glide® Limited rides on cast aluminum wheels at both ends. The front wheel measures 19 inches in diameter and 3.5 inches in width, while the rear wheel measures 18 inches in diameter and 5 inches in width. Tire equipment consists of Dunlop® Harley-Davidson® Series bias blackwall tires. The front tire is specified as a D408F in size 130/60B19 M/C 61H, and the rear tire is a D407T in size 180/55B18 M/C 80H. Together, the wheel and tire package supports the motorcycle’s chassis geometry and operating characteristics.
Braking Systems and Rider Safety Technology
The braking system on the 2026 Harley-Davidson® Street Glide® Limited combines substantial hardware with a comprehensive collection of electronic rider-assistance technologies. Front braking utilizes dual floating rotors paired with 32 mm four-piston fixed dual axially mounted calipers. The rear braking system uses a fixed rotor and a single axially mounted caliper. Front rotor diameter measures 12.6 inches with a thickness of 0.18 inch, while the rear rotor measures 11.8 inches in diameter and 0.28 inch in thickness.
Integrated Rider Safety Enhancements
Anti-lock Braking System functionality is included as standard equipment. The motorcycle also incorporates Electronic Linked Braking, Traction Control System, Drag-torque Slip Control System, Vehicle Hold Control, and Tire Pressure Monitoring System. These systems contribute additional layers of electronic assistance that support braking performance, traction management, and rider awareness. The integration of these technologies reflects the model’s emphasis on advanced rider-support functionality. Each system operates as part of a broader package intended to enhance rider confidence and vehicle control.
Cornering Safety Technologies
The 2026 Harley-Davidson® Street Glide® Limited further expands its safety technology package through a suite of cornering-oriented systems. Included equipment consists of a Cornering Enhanced Anti-lock Brake System, Cornering Enhanced Electronic Linked Braking, Cornering Enhanced Traction Control System, and Cornering Drag-Torque Slip Control System. These technologies supplement the motorcycle’s standard rider safety enhancements with additional cornering-focused functionality. The availability of both standard and cornering-enhanced systems demonstrates the depth of the model’s electronic safety package. Together, these technologies create a comprehensive suite of rider-assistance features.
Electrical Systems and Lighting
The electrical architecture of the 2026 Harley-Davidson® Street Glide® Limited supports starting, charging, lighting, infotainment, and accessory functions. Power is supplied by a sealed, maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold cranking amps. Charging duties are handled by a three-phase 58-amp system capable of producing up to 754 watts at 13 volts. Engine starting is managed through a 1.6 kW electric starter featuring solenoid-shift starter motor engagement. These components form the foundation of the motorcycle’s electrical infrastructure.
LED Lighting Equipment
Lighting throughout the motorcycle utilizes LED technology. The headlamp, tail lamp, stop lamp, front signal lights, and rear turn signals are all specified as LED units. Additional LED fog lamps are integrated into the lower fairings. This lighting package provides a consistent approach across major lighting functions. Digital gauges are integrated directly within the display system, consolidating vehicle information within the motorcycle’s technology interface.
Infotainment, Connectivity, and Navigation
The infotainment system of the 2026 Harley-Davidson® Street Glide® Limited is built around Skyline™ OS and displayed through a 12.3-inch full-color TFT screen. The system combines entertainment, navigation, communication, and vehicle-information functions within a centralized interface. Audio output is delivered through a four-speaker configuration rated at 50 watts per channel. Two 6.5-inch speakers are mounted in the fairing, while two additional 6.5-inch speakers are located in the Tour-Pak®.
Audio and Communication Features
AM and FM radio functionality are included as standard equipment. The system also supports SD cards, flash drives, and MP3 playback through USB connectivity. Bluetooth® hands-free mobile phone functionality is standard, and Bluetooth® support extends to phone, media player, and headset connections. Rider and passenger intercom capability is available when compatible headsets are used. VOX functionality is available for H-D headsets, expanding communication capabilities within the system.
Navigation and Device Integration
The 2026 Harley-Davidson® Street Glide® Limited includes an embedded GPS navigation system that provides traffic and weather information through a Wi-Fi hotspot connection. Apple CarPlay® compatibility is available through both wireless and wired connections. USB-C connectivity is supported through a connection located in the inner fairing storage area and can work with compatible smartphones using appropriate adapters. The vehicle information screen provides access to functions including air temperature, oil pressure, and EITMS information. These integrated technologies create a comprehensive information and connectivity environment for touring riders.
Comfort, Storage, and Touring Functionality
The 2026 Harley-Davidson® Street Glide® Limited incorporates several features intended to support long-distance travel and everyday usability. The motorcycle provides 5.05 cubic feet of luggage volume, offering substantial onboard storage capacity. Integrated storage is complemented by accessory power solutions that support electronic devices and rider equipment. These utility-focused features contribute to the motorcycle’s overall touring capability while maintaining integration with the broader vehicle design.
Power Access and Functional Equipment
A 15-watt USB-C electric power accessory port is located within the media storage box. An additional electric power accessory port is integrated into the Tour-Pak®. These power outlets provide charging and accessory support for compatible devices carried during travel. Combined with the motorcycle’s infotainment system, navigation features, luggage capacity, and communication technologies, these utility features contribute to a comprehensive touring equipment package. The result is a motorcycle that combines performance, rider technology, storage, and comfort-oriented functionality within a single integrated platform.
